| Brand | Gustav Klein |
|---|---|
| Voltage rating | 800-1100 V DC |
| Capacitance | 2500-20360 uF (buffer types); 2.5-5.8 mF (local-mount MKP types) |
| Housing | Plastic (IP65) or metal |
| Protection | Makrolon touch-protection cover |
Capacitor Box
Key Features
- Electrolytic capacitors buffer load spikes; MKP capacitors divert ripple current close to the test specimen
- Plastic housing (IP65) or metal housing, depending on variant
- Voltage ratings from 800 V to 1100 V DC
- Touch protection via a Makrolon cover with the door open
- Local-mounting metal variants (1100 V) include copper bars for adjusting capacitance and discharge resistors
| Model | Description |
|---|---|
| Capabox-P-800-19800 | Plastic housing, 800 V, 19800 uF, IP65. |
| Capabox-P-1000-8100 | Plastic housing, 1000 V, 8100 uF, IP65. |
| Capabox-P-1000-20000 | Plastic housing, 1000 V, 20000 uF, IP65. |
| Capabox-M-800-20360 | Metal housing, 800 V, 20360 uF (incl. MKP capacitors for voltage-peak reduction). |
| Capabox-M-1000-9660 | Metal housing, 1000 V, 9660 uF (incl. MKP capacitors for voltage-peak reduction). |
| Capabox-M-1100-2500 | Metal housing with MKP capacitors, 1100 V, 2.5 mF, for local mounting on the DUT. |
| Capabox-M-1100-5800 | Metal housing with MKP capacitors, 1100 V, 5.8 mF, for local mounting on the DUT. |
Capacitor Box
When an I-TS system is used as a battery simulator, feedback from the test specimen can affect the whole system. The capacitor box reduces this feedback: it is connected as directly as possible to the test specimen, with electrolytic capacitors buffering load spikes and MKP capacitors diverting ripple currents close to the DUT. Available in plastic (IP65) or metal housing.Who Is the Capacitor Box For?
Test engineers running battery simulation on an I-TS system, where feedback from the test specimen needs to be buffered or its ripple current reduced close to the DUT.Available Models & Accessories
Capacitor boxes are available in plastic housing (800-1000 V, 8100-20000 uF) and metal housing (800-1100 V, including local-mount MKP variants up to 5.8 mF).Two capacitor technologies, two jobs
Electrolytic capacitors buffer load spikes for simulator operation, while MKP capacitors specifically divert ripple currents close to the DUT; the metal-housing variants combine both.
Local mounting reduces interference at the source
The 1100 V MKP variants are designed to mount directly on the DUT rather than in the main cabinet, cutting the cable length that picks up interference.
Capacitance is field-adjustable on the local-mount variants
Copper bars let the capacitance be changed on site (e.g. to 830, 1660 or 2490 uF) without swapping the unit.
Housing matches the installation
A plastic IP65 enclosure for general use, or a metal enclosure where the added MKP capacitors and local mounting are needed.
