Hybrid Antennas
The TBMA8 Hybrid Antenna is an EMC antenna designed to provide comprehensive coverage for pre-compliance testing. It delivers high performance with a wide frequency range of 30 MHz to 3000 MHz and a power handling capacity of 130W. This hybrid design provides a versatile solution that significantly reduces the need for frequent antenna changes during testing.
Key Specifications & Features
- Frequency Range: 30 MHz to 3000 MHz
- Power Handling: 130W
- Antenna Factor: 8 to 34 dB/m
- Design Type: Hybrid (combined characteristics)
- Application: EMC pre-compliance testing
- Compatibility: Standard RF measurement equipment
- Efficiency: Reduced antenna swapping requirements
- Reliability: Consistent performance across extended bands
| Model | Frequency Range | Max Input Power | Antenna Factor |
|---|---|---|---|
| TBMA8 | 30..3000 MHz | 130 W | 8..34 dB/m |
| TBMA11 | 130..6000 MHz | 130 W | 7..41 dB/m |
| TBMA12 | 30..6000 MHz | 130 W | 7..42 dB/m |
Hybrid Antennas
The Hybrid Antennas series, featuring the TBMA8 model, is engineered to provide a comprehensive solution for EMC pre-compliance testing. By integrating the unique characteristics of multiple antenna types into a single unit, it allows for seamless monitoring across a broad spectrum. This versatility makes it an essential tool for laboratories looking to streamline their electromagnetic interference analysis. The core technology of the TBMA8 allows it to cover an extended frequency range from 30 MHz up to 3000 MHz. Its robust construction supports a power handling capability of 130W and provides an antenna factor ranging from 8 to 34 dB/m. This hybrid approach ensures that engineers can capture accurate data without the downtime typically associated with switching between specialized antennas. These antennas are designed for maximum compatibility with standard RF measurement equipment, ensuring they can be integrated into existing test setups with ease. The TBMA8 model is the primary configuration, though custom solutions and tailored offers can be requested to meet specific laboratory requirements. This series represents a cost-effective and efficient choice for professional pre-compliance environments.Wide Frequency Spectrum
Covers a broad range from 30 MHz to 3000 MHz for comprehensive testing versatility.
High Power Handling
Capable of managing up to 130W of power to suit various measurement and testing scenarios.
Optimized Antenna Factor
Features an antenna factor between 8 and 34 dB/m for precise and reliable measurement results.
Pre-Compliance Optimized
Specifically engineered to meet the rigorous demands of EMC pre-compliance test environments.
Broad Spectrum Coverage
The TBMA8 Hybrid antenna is specifically designed to bridge the gap between different antenna types, offering an impressive frequency range from 30 MHz to 3 GHz. This wide coverage is critical for identifying emissions across multiple bands during a single test session, ensuring no interference goes undetected.
Enhanced Testing Efficiency
By combining the characteristics of multiple antenna designs, this unit eliminates the logistical burden of manual antenna changes. This streamlined workflow improves overall lab productivity and ensures full compatibility with a wide variety of standard RF measurement instruments and receivers.
