| Brand | Tekbox |
|---|
Near Field Probes
The TBPS01 Near Field Probes are professional measurement tools designed to measure localized electric or magnetic fields close to electronic circuits. These probes are optimized for EMC debugging and source identification, allowing for precise localization of interference. The kits offer high versatility with multiple probe sizes and optional wideband amplification for low-level signals.
Key Specifications & Features
- Magnetic Field Probes: H20, H10, and H5 included
- Electric Field Probe: E5 included
- Application: Localized EMC debugging and source identification
- Amplification: Optional 20dB or 40dB wideband amplifiers
- Connectivity: 75cm SMB to SMA and SMA to N cables
- Adapters: SMA-female to N-male coaxial adapter included
- Documentation: Measurement plots provided for accurate analysis
- Storage: Protective wooden case for all components
| TBPS01 | EMC Sniffer Probe set consisting of H20, H10, H5 Magnetic and E5 Electric Field Probes, 75cm SMB to SMA cable, measurement plots, SMA-female to N-male coaxial adapter, wooden case |
| TBPS01-TBWA2/20dB | EMC Sniffer Probe set consisting of H20, H10, H5 Magnetic and E5 Electric Field Probes, TBWA2/20dB wideband amplifier, 75cm SMB to SMA cable, 75cm SMA to N cable, USB cable, wooden case, measurement |
| TBPS01-TBWA2/40dB | EMC Sniffer Probe set consisting of H20, H10, H5 Magnetic and E5 Electric Field Probes, TBWA2/40dB wideband amplifier, 75cm SMB to SMA cable, 75cm SMA to N cable, USB cable, wooden case, measurement |
Near Field Probes
The TBPS01 Near Field Probes are essential instruments for engineers performing localized electromagnetic compatibility (EMC) testing. These probes are specifically designed to measure both electric and magnetic fields in close proximity to electronic circuits and PCB components. By utilizing different probe sizes, users can balance sensitivity and spatial resolution to identify the exact source of interference. Constructed for precision and durability, the set includes magnetic field probes (H20, H10, H5) and an electric field probe (E5). This variety allows for the detection of emissions from large traces down to individual component pins. The probes are intended for use with spectrum analyzers or oscilloscopes to facilitate rapid debugging and source identification during the design phase. The TBPS01 series is available in multiple configurations, including standalone sets or bundles featuring TBWA2 wideband amplifiers. These amplifiers offer either 20dB or 40dB of gain to ensure that even low-level emissions are clearly visible during analysis. Every set comes complete with high-quality SMB to SMA cables, necessary adapters, and a professional wooden case for organized storage.Comprehensive Probe Selection
Includes H20, H10, and H5 magnetic probes plus E5 electric probes for versatile testing.
Signal Gain Options
Available wideband amplifiers provide 20dB or 40dB gain to enhance low-level signal detection.
Professional Storage Case
All components are organized and protected within a high-quality wooden carrying case.
Complete Cable Kit
Sets include SMB to SMA cables, SMA to N adapters, and USB cables for immediate setup.
EMC Debugging and Source Identification
These probes are specifically designed to locate the sources of electromagnetic interference within electronic circuits. By measuring localized electric and magnetic fields, engineers can pinpoint problematic components or traces. This identification process is crucial for passing regulatory compliance tests and improving overall circuit design.
Integrated Amplification and Accessories
The TBPS01 sets provide a complete measurement solution by including necessary adapters and high-quality cables. For low-level signals, specific models include TBWA2 wideband amplifiers with either 20dB or 40dB gain. These components are housed in a durable wooden case to ensure the precision probes remain protected during transport and storage.
