| Brand | RIGOL |
|---|---|
| Output Frequency | 40 MHz |
| Channels | 2 |
| Vertical Resolution | 16-bit |
| Sample rate | up to 125 MSa/s |
DG800 Pro Function Generators/AWG
The DG800 Pro Series is a compact, professional arbitrary waveform generator platform designed for precision signal generation in embedded systems, analog design, power electronics, and automated test environments
Key Specifications & Features
- Output Frequency: up to 40 MHz
- Channels: 2
- Vertical Resolution: 16-bit
- Sample Rate: up to 125 MSa/s
- Arbitrary Memory: up to 16 Mpts
- Waveforms: standard, arbitrary, noise, pulse
- Interfaces: USB, LAN
- Benefits: high vertical resolution; compact design; excellent signal accuracy for professional use
DG800 Pro Function Generators/AWG - Overview
The DG800 Pro Series is offered in multiple model variants built on a shared hardware and signal generation platform. All models provide identical core functionality, dual-channel architecture, and 16-bit vertical resolution, with differentiation primarily based on output frequency and sampling performance.
The series covers output frequency requirements from 25 MHz to 50 MHz, allowing users to select the appropriate performance level according to application needs without compromising signal accuracy or waveform quality. Sampling rates reach approximately 625 MSa/s, ensuring reliable waveform reproduction for timing-critical and high-fidelity signal generation tasks.
This clear model separation simplifies selection by aligning frequency capability with intended use, while maintaining consistent operation and feature availability across the platform.
Selectable output bandwidth
25 MHz to 50 MHz output frequency range depending on selected model.
Consistent 16-bit resolution
High vertical resolution maintained across all DG800 Pro models.
Dual-channel architecture
All models provide two output channels for flexible signal generation.
High-speed sampling performance
Sampling rates up to approximately 625 MSa/s support accurate waveform reproduction.
Expandable platform via optional upgrades
In addition to base model selection, the DG800 Pro platform supports functional expansion through optional upgrades. These options enable the instrument to adapt to evolving test requirements while preserving the original hardware investment. Available upgrades include expanded arbitrary waveform memory, increasing storage capacity for longer and more complex waveform sequences, as well as channel capability expansion, supporting more advanced multi-signal test scenarios. This modular approach allows users to configure the system according to current needs and extend functionality as application complexity grows. Options may be selected during initial purchase or added later depending on configuration requirements and deployment context.
Configuration guidance
Model selection within the DG800 Pro Series is typically driven by required output frequency, while optional upgrades address memory depth and channel flexibility. Detailed model specifications and available upgrade options are listed in the Models & Options section above. For assistance with selecting the most appropriate configuration, consultation with a technical specialist is recommended.
