| Brand | Tekbox |
|---|
Vector Network Analyzer
The TBVNA Series Vector Network Analyzer is a professional test instrument designed to measure reflection and transmission parameters of RF components. It offers a wide frequency range from 0.1 Hz to 6 GHz for precise characterization of cables, antennas, and EMC accessories. The series provides exceptional versatility with an available Bode option for advanced frequency response analysis.
Key Specifications & Features
- Frequency Range: 0.1 Hz to 6 GHz
- Measurement Parameters: Reflection and transmission (S-parameters)
- Analysis Type: Frequency-domain analysis
- Applications: Antenna and cable characterization
- EMC Testing: Suitable for EMC accessory verification
- Bode Option: Available on TBVNA-6000-B model
- Versatility: Supports a wide range of RF component testing
- Model Range: Includes standard and Bode-equipped versions
| TBVNA-6000 | 0.1 Hz – 6 GHz Vector Network Analyzer |
| TBVNA-6000-B | 0.1 Hz – 6 GHz Vector Network Analyzer with Bode option |
No downloads available.
Vector Network Analyzer
The TBVNA Series Vector Network Analyzer is a high-performance solution for engineers needing to measure reflection and transmission parameters in RF systems. With a broad frequency range spanning from 0.1 Hz up to 6 GHz, these instruments are ideal for the detailed characterization of various RF components. Whether testing in the lab or the field, the TBVNA provides the frequency-domain analysis required for modern electronic design.
Built for precision and reliability, the TBVNA series utilizes advanced measurement technology to evaluate cables, antennas, and EMC accessories. The ability to accurately assess signal integrity and component performance makes it an essential tool for RF development and quality assurance. Its robust construction ensures consistent results across the entire 6 GHz bandwidth.
The series offers multiple configurations to meet specific testing needs, including the standard TBVNA-6000 and the TBVNA-6000-B. The latter comes equipped with a Bode option, expanding the analyzer's capabilities for frequency response measurements. This range of models allows users to select the exact feature set required for their specific RF and EMC applications.
Wide Frequency Range
Covers a broad spectrum from 0.1 Hz to 6 GHz for comprehensive RF testing.
Dual Parameter Analysis
Measures both reflection and transmission parameters for full component characterization.
Antenna & Cable Testing
Optimized for the precise characterization of antennas, cables, and EMC accessories.
Optional Bode Functionality
Available models include a Bode option for expanded frequency-domain analysis.
Precision RF Component Characterization
The TBVNA Series provides comprehensive measurement of reflection and transmission parameters, which is critical for evaluating RF components. By utilizing frequency-domain analysis, users can gain deep insights into the performance of cables and antennas. This ensures that all parts of the RF signal chain meet the necessary specifications for professional applications.
Advanced Bode Plot Capabilities
Selected models within the TBVNA series, such as the TBVNA-6000-B, feature an integrated Bode option. This allows for specialized analysis of gain and phase across the 0.1 Hz to 6 GHz spectrum. It is an invaluable feature for characterizing the frequency response of filters, amplifiers, and various EMC accessories.
