| Brand | Impulse Technologies |
|---|---|
| Frequency coverage | MHz to 40+ GHz |
| RF Power | 50–200 W average, up to 3 kW peak |
| Operating Temperature | -55 °C to +125 °C |
RF & Microwave Oscillators
The RF & Microwave Oscillators is a high-performance signal source series designed to provide stable signal generation across a wide frequency range. These units offer coverage from MHz to 40+ GHz with output power levels ranging from +5 to +15 dBm. They feature MIL-DTL-22641 compliance and low phase noise performance for demanding environments.
Key Specifications & Features
- Frequency Range: MHz to 40+ GHz
- Output Power: +5 to +15 dBm
- Peak RF Power: Up to 3kW peak
- Connector Options: 2.92mm, SMA, and Type N (Stainless Steel)
- Design Types: Free-running and PLL designs
- Operating Temperature: -55°C to +125°C
- Construction: Aluminum body with CPRF or COVER flanges
- Compliance: MIL-DTL-22641 standards
No downloads available.
RF & Microwave Oscillators
These RF & Microwave Oscillators are engineered for precise frequency control and stable signal generation across an expansive spectrum from MHz to over 40 GHz. Designed for versatility, the series includes both free-running and Phase-Locked Loop (PLL) architectures to meet various application requirements. With output power ranging from +5 to +15 dBm, these oscillators ensure reliable performance for test, measurement, and communication systems.
Built for durability and high-power handling, the units feature a rugged aluminum body and high-quality stainless steel connectors including 2.92mm, SMA, and Type N formats. The series supports significant power levels, with average RF power between 50-200W and peak power reaching up to 3kW. For waveguide-specific needs, models such as WR42, WR34, and WR28 are available, maintaining 1kW peak performance while ensuring low phase noise and spectral purity.
These oscillators are fully compliant with MIL-DTL-22641 specifications, making them suitable for extreme environmental conditions with a wide temperature range of -55°C to +125°C. Flange options include CPRF and COVER styles to facilitate seamless integration into existing microwave setups and waveguide systems. Whether for laboratory use or field deployment, these oscillators provide the stability required for modern RF engineering.
Wide Frequency Coverage
Provides stable signal generation across a range from MHz up to 40+ GHz.
High Power Handling
Supports average RF power up to 200W and peak power levels up to 3kW.
Low Phase Noise
Engineered for high-stability applications requiring clean and precise signal outputs.
Industrial Grade Durability
Features stainless steel connectors and an aluminum body compliant with MIL-DTL-22641.
Robust Construction and Mil-Spec Compliance
These oscillators are housed in a rugged aluminum body and feature high-quality stainless steel connectors for long-term reliability. They are designed to meet MIL-DTL-22641 standards, ensuring they can withstand extreme temperatures ranging from -55°C to +125°C.
Versatile Signal Generation Options
The series offers a broad frequency coverage from MHz to 40+ GHz with both free-running and PLL design options. Users can select from various connector types including 2.92mm, SMA, and Type N to match their specific system interface needs.
